Please contact us for more photos of 207584-7
| Part Number | 207584-7 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 108680 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board PIN 10 POS 5mm Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 207584-7 |
| Datasheet download |  207584-7.pdf |
| Part Number | 207584-7 |
|---|---|
| Housing Material | Thermoplastic |
| Housing Color | Red |
| Contact Material | Copper Alloy |
| Product Dimensions | 71.86 x 12.7 x 17.5 mm |
| Pitch | 5 mm |
| Mounting | Through Hole |
| Type | Wire to Board |
| Gender | PIN |
| Number of Rows | 1 |
| Number of Contacts | 10 |
| Rad Hard | No |
| Body Orientation | Straight |
| Maximum Current Rating | 14/Contact |
| Termination Method | Solder |
| Operating Temperature | -55 to 130 °C |
| Max Processing Temp | 240|260|265 |
| Maximum Voltage Rating | 600 |
| Contact Plating | Tin |
| Product Depth | 12.7 mm |
| Product Height | 17.5 mm |
| Product Length | 71.86 mm |
| Replacement Part Number | PART-207584-7 |
| Weight | Contact us |
| Country of Origin | - |
