Please contact us for more photos of 2-1761608-3
| Part Number | 2-1761608-3 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 359780 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Ejector Header HDR 10 POS 2.54mm Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 2-1761608-3 |
| Datasheet download |  2-1761608-3.pdf |
| Part Number | 2-1761608-3 |
|---|---|
| Termination Method | Solder |
| Housing Color | Blue |
| Body Orientation | Straight |
| Operating Temperature | -65 to 105 °C |
| Lead Finish | Tin |
| Gender | HDR |
| Max Processing Temp | 240|260|265 |
| Mounting | Through Hole |
| Contact Plating | Gold Over Nickel |
| Pitch | 2.54 mm |
| Rad Hard | No |
| Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic |
| Product Dimensions | 20.32 x 18.49 mm |
| Product Height | 18.49 mm |
| Product Length | 20.32 mm |
| Replacement Part Number | PART-2-1761608-3 |
| Weight | Contact us |
| Country of Origin | - |
