Please contact us for more photos of 178307-3
| Part Number | 178307-3 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 465310 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Power HDR 16 POS 3.81mm Solder RA Thru-Hole 16 Terminal 1 Port Tube |
| Category | Connectors |
| Family | Connector Power |
| ROHS Compliant | Yes |
| MSL Level | 178307-3 |
| Datasheet download |  178307-3.pdf |
| Part Number | 178307-3 |
|---|---|
| Termination Method | Solder |
| Number of Contacts | 16 |
| Housing Material | Nylon |
| Number of Terminals | 16 |
| Max Processing Temp | 240|260|265 |
| Mounting | Through Hole |
| Number of Ports | 1 |
| Body Orientation | Right Angle |
| Gender | HDR |
| Contact Plating | Gold Over Nickel |
| Contact Material | Copper Alloy |
| Rad Hard | No |
| Product Dimensions | 40.67 x 25.91 x 15.93 mm |
| Lead Finish | Gold |
| Operating Temperature | -55 to 105 °C |
| Type | Power |
| Pitch | 3.81 mm |
| Product Depth | 25.91 mm |
| Product Height | 15.93 mm |
| Product Length | 40.67 mm |
| Replacement Part Number | PART-178307-3 |
| Weight | Contact us |
| Country of Origin | - |
