Please contact us for more photos of 1318125-1
| Part Number | 1318125-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 683040 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Power M 8 POS 2.5mm Solder ST Thru-Hole 8 Terminal 1 Port Tube |
| Category | Connectors |
| Family | Connector Power |
| ROHS Compliant | Yes |
| MSL Level | 1318125-1 |
| Datasheet download |  1318125-1.pdf |
| Part Number | 1318125-1 |
|---|---|
| Termination Method | Solder |
| Product Dimensions | 12.7 x 13.2 x 17.79 mm |
| Body Orientation | Straight |
| Mounting | Through Hole |
| Max Processing Temp | 240|260|265 |
| Gender | M |
| Operating Temperature | -55 to 105 °C |
| Housing Material | Polyester |
| Pitch | 2.5 mm |
| Contact Material | Copper Alloy |
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Lead Finish | Gold |
| Product Depth | 13.2 mm |
| Product Height | 17.79 mm |
| Product Length | 12.7 mm |
| Replacement Part Number | PART-1318125-1 |
| Weight | Contact us |
| Country of Origin | - |
