Please contact us for more photos of 120958-2
| Part Number | 120958-2 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 611010 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Daughter Card HDR 8 POS 2mm Press Fit RA Thru-Hole |
| Category | Connectors |
| Family | Connector Backplane |
| ROHS Compliant | Yes |
| MSL Level | 120958-2 |
| Datasheet download |  120958-2.pdf |
| Part Number | 120958-2 |
|---|---|
| Housing Color | Gray |
| Contact Material | Copper Alloy |
| Number of Rows | 1 |
| Rad Hard | No |
| Housing Material | Polyester |
| Contact Plating | Gold Over Nickel |
| Termination Method | Press Fit |
| Pitch | 2 mm |
| Product Dimensions | 27 x 22.34 x 14.28 mm |
| Number of Contacts | 8 |
| Mounting | Through Hole |
| Body Orientation | Right Angle |
| Lead Finish | Tin |
| Gender | HDR |
| Type | Daughter Card |
| Product Depth | 22.34 mm |
| Product Height | 14.28 mm |
| Product Length | 27 mm |
| Replacement Part Number | PART-120958-2 |
| Weight | Contact us |
| Country of Origin | - |
