Please contact us for more photos of 1-338313-2
| Part Number | 1-338313-2 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 363460 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn D-Subminiature SKT 9 POS 2.74mm Solder ST Thru-Hole 9 Terminal 1 Port |
| Category | Connectors |
| Family | Connector D-Subminiature |
| ROHS Compliant | Yes |
| MSL Level | 1-338313-2 |
| Datasheet download |  1-338313-2.pdf |
| Part Number | 1-338313-2 |
|---|---|
| Product Dimensions | 30.9 x 12.4 x 12.1 mm |
| Number of Contacts | 9 |
| Termination Method | Solder |
| Body Orientation | Straight |
| Max Processing Temp | 240|260|265 |
| Type | D-Subminiature |
| Number of Terminals | 9 |
| Number of Ports | 1 |
| Lead Finish | Tin |
| Mounting | Through Hole |
| Contact Plating | Gold Over Nickel |
| Housing Material | Polyester |
| Rad Hard | No |
| Gender | SKT |
| Contact Material | Phosphor Bronze |
| Operating Temperature | -55 to 105 °C |
| Pitch | 2.74 mm |
| Product Depth | 12.4 mm |
| Product Height | 12.1 mm |
| Product Length | 30.9 mm |
| Replacement Part Number | PART-1-338313-2 |
| Weight | Contact us |
| Country of Origin | - |
