Please contact us for more photos of 1-178298-5
| Part Number | 1-178298-5 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 149150 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Power M 10 POS 3.81mm Solder RA Thru-Hole 10 Terminal 1 Port Tube |
| Category | Connectors |
| Family | Connector Power |
| ROHS Compliant | Yes |
| MSL Level | 1-178298-5 |
| Datasheet download |  1-178298-5.pdf |
| Part Number | 1-178298-5 |
|---|---|
| Termination Method | Solder |
| Product Dimensions | 48.29 x 22.1 x 10.85 mm |
| Body Orientation | Right Angle |
| Max Processing Temp | 240|260|265 |
| Gender | M |
| Mounting | Through Hole |
| Pitch | 3.81 mm |
| Operating Temperature | -55 to 105 °C |
| Rad Hard | No |
| Contact Material | Copper Alloy |
| Contact Plating | Tin Over Nickel |
| Housing Material | Polyester |
| Product Depth | 22.1 mm |
| Product Height | 10.85 mm |
| Product Length | 48.29 mm |
| Replacement Part Number | PART-1-178298-5 |
| Weight | Contact us |
| Country of Origin | - |
