Please contact us for more photos of B82422-T1334-K
| Part Number | B82422-T1334-K |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 486250 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind General Purpose Chip Molded Wirewound 330uH 10% 796KHz 20Q-Factor Ferrite 40mA 1210 Blister T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | B82422-T1334-K |
| Datasheet download |  B82422-T1334-K.pdf |
| Part Number | B82422-T1334-K |
|---|---|
| Technology | Wirewound |
| Test Frequency | 796 kHz |
| Product Dimensions | 3.6 x 2.9 x 2.3 mm |
| Type | General Purpose Chip |
| Rad Hard | No |
| Tolerance | 10 % |
| Max Processing Temp | 260 |
| Package/Case | 1210 |
| Protection Style | Molded |
| Lead Finish | Tin |
| MSL Level | 1 |
| Product Depth | 2.9 mm |
| Product Height | 2.3 mm |
| Product Length | 3.6 mm |
| Replacement Part Number | PART-B82422-T1334-K |
| Weight | Contact us |
| Country of Origin | - |
