Part Number | B32914A3225M |
---|---|
Manufacturer | TDK |
Quantity in stock | 394170 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Cap Film 2.2uF 330VAC PP 20% 41.5 X 18 X 32.5mm RDL 27.5mm Bulk |
Category | Capacitors |
Family | Capacitor Film |
ROHS Compliant | Yes |
MSL Level | B32914A3225M |
Datasheet download | ![]() |
Part Number | B32914A3225M |
---|---|
Mounting | Through Hole |
Termination Style | Radial |
Rad Hard | No |
Seated Plane Height | 32.5 mm |
Voltage(AC) | 330 V |
Max Processing Temp | 260 |
Tolerance | 20 % |
Dielectric | PP |
Lead Finish | Matte Tin |
Capacitance Value | 2.2 uF |
Lead Pitch For Radial | 27.5 mm |
Product Dimensions | 41.5 x 18 x 32.5 mm |
Operating Temperature | -40 to 110 °C |
Package/Case | 41.5(Max) X 18(Max) X 32.5(Max) |
Product Depth | 18(Max) mm |
Product Height | 32.5(Max) mm |
Product Length | 41.5(Max) mm |
Replacement Part Number | PART-B32914A3225M |
Weight | Contact us |
Country of Origin | - |
