Please contact us for more photos of B32523Q1106K
| Part Number | B32523Q1106K |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 394590 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 10uF 100V PET 10% (26.5 X 10.5 X 16.5mm) Radial 22.5mm 125\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | B32523Q1106K |
| Datasheet download |  B32523Q1106K.pdf |
| Part Number | B32523Q1106K |
|---|---|
| Voltage(DC) | 100 V |
| Package/Case | 26.5(Max) X 10.5(Max) X 16.5(Max) |
| Dielectric | PET |
| Mounting | Through Hole |
| Termination Style | Radial |
| Seated Plane Height | 16.5 mm |
| Rad Hard | No |
| Lead Pitch For Radial | 22.5 mm |
| Lead Finish | Matte Tin |
| Tolerance | 10 % |
| Operating Temperature | -55 to 125 °C |
| Capacitance Value | 10 uF |
| Max Processing Temp | 260 |
| Product Dimensions | 26.5 x 10.5 x 16.5 mm |
| Voltage(AC) | 63 V |
| Product Depth | 10.5(Max) mm |
| Product Height | 16.5(Max) mm |
| Product Length | 26.5(Max) mm |
| Replacement Part Number | PART-B32523Q1106K |
| Weight | Contact us |
| Country of Origin | - |
