EVQPAE04M Panasonic

EVQPAE04M Images

Please contact us for more photos of EVQPAE04M

Part Number EVQPAE04M
Manufacturer Panasonic
Quantity in stock 293760 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Switch Tactile N.O. SPST Round Button PC Pins 0.02A 15VDC 1.6N Thru-Hole Bulk
Category Switches and Relays
Family Switches
ROHS Compliant Yes
MSL Level EVQPAE04M
Datasheet download EVQPAE04M.pdf
Request Quotation for EVQPAE04M

EVQPAE04M Specifications

Part Number EVQPAE04M
Pole Throw Configuration SPST
Max Processing Temp 250 to 260
Product Dimensions 6 x 7.8 x 4.3 mm
Maximum DC Voltage Rating 15 V
Maximum Current Rating 0.02@15VDC A
Mounting Through Hole
Lead Finish Gold|Silver
Switch Configuration N.O.
Rad Hard No
Actuator Style Round Button
Terminal Type PC Pins
Type Light Touch
Operating Temperature -20 to 70 °C
Replacement Part Number PART-EVQPAE04M
Weight Contact us
Country of Origin -
