Please contact us for more photos of EVPAWCD2AF30
| Part Number | EVPAWCD2AF30 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 473280 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Tactile N.O. SPST Flat Button Gull Wing 0.02A 15VDC 500000Cycles 2.4N Surface Mount Embossed T R |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | EVPAWCD2AF30 |
| Datasheet download |  EVPAWCD2AF30.pdf |
| Part Number | EVPAWCD2AF30 |
|---|---|
| Illumination Type | |
| Operating Force | |
| Maximum AC Voltage Rating | |
| Maximum Power Rating | |
| Rad Hard | No |
| Supplier Package | SMD |
| Pin Count | 2 |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Switch Configuration | N.O. |
| Product Dimensions | 3 x 2 x 0.6 |
| Actuator Style | Flat Button |
| Type | Light Touch |
| Mounting | Surface Mount |
| Pole Throw Configuration | SPST |
| Maximum DC Voltage Rating | 15 V |
| Mechanical Life | 300000 Cycles |
| Maximum Current Rating | 0.02 A |
| Terminal Type | Gull Wing |
| Replacement Part Number | PART-EVPAWCD2AF30 |
| Weight | Contact us |
| Country of Origin | - |
