1301.9318.24 SCHURTER

1301.9318.24 Images

Please contact us for more photos of 1301.9318.24

Part Number 1301.9318.24
Manufacturer SCHURTER
Quantity in stock 253610 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description LSH 6X6 SHORT TRAVEL SWITCH 8.00MM
Category Switches and Relays
Family Switches
ROHS Compliant Yes
MSL Level 1301.9318.24
Datasheet download 1301.9318.24.pdf
Request Quotation for 1301.9318.24

1301.9318.24 Specifications

Part Number 1301.9318.24
Actuator Style Round Button
Product Dimensions 6 x 10 x 8 mm
Operating Temperature -20 to 70 °C
Operating Force 1.6 N
Max Processing Temp 240
Switch Configuration N.O.
Maximum DC Voltage Rating 12 V
Pole Throw Configuration SPST
Rad Hard No
Mechanical Life 100000 Cycles
Lead Finish Silver
Maximum Current Rating 0.05 A
Terminal Type Gull Wing
Mounting Surface Mount
Replacement Part Number PART-1301.9318.24
Weight Contact us
Country of Origin -
