Please contact us for more photos of 1301.9306
| Part Number | 1301.9306 |
|---|---|
| Manufacturer | SCHURTER |
| Quantity in stock | 666570 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | LPH 6X6 SHORT TRAVEL SWITCH 9.5MM |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | 1301.9306 |
| Datasheet download |  1301.9306.pdf |
| Part Number | 1301.9306 |
|---|---|
| Rad Hard | No |
| Maximum Current Rating | 0.05 A |
| Mechanical Life | 100000 Cycles |
| Actuator Style | Round Button |
| Operating Temperature | -20 to 70 °C |
| Pole Throw Configuration | SPST |
| Product Dimensions | 6 x 9.5 mm |
| Max Processing Temp | 260 |
| Maximum DC Voltage Rating | 12 V |
| Terminal Type | PC Pins |
| Switch Configuration | N.O. |
| Mounting | Through Hole |
| Operating Force | 1.6 N |
| Replacement Part Number | PART-1301.9306 |
| Weight | Contact us |
| Country of Origin | - |
