Please contact us for more photos of PZ2012U600-3R0TF
| Part Number | PZ2012U600-3R0TF |
|---|---|
| Manufacturer | SHENZHEN SUNLORD ELECTRONICS |
| Quantity in stock | 158230 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Chip Bead Shielded Multi-Layer 60 Ohm 25% 100MHz Ferrite 3A 0805 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | PZ2012U600-3R0TF |
| Datasheet download |  PZ2012U600-3R0TF.pdf |
| Part Number | PZ2012U600-3R0TF |
|---|---|
| Rad Hard | No |
| Test Frequency | 100 MHz |
| Maximum DC Resistance | 0.025 Ohm |
| Protection Style | Shielded |
| Operating Temperature | -55 to 125 °C |
| Pin Count | 2 |
| Package/Case | 0805 |
| Supplier Package | 0805 |
| Type | Chip Bead |
| Tolerance | 25 % |
| Maximum DC Current | 3 A |
| Core Material | Ferrite |
| Package Dimensions | 2 x 1.25 x 0.85 mm |
| Impedance | 60 Ohm |
| Technology | Multilayer |
| Product Depth | 1.25 mm |
| Product Height | 0.85 mm |
| Product Length | 2 mm |
| Replacement Part Number | PART-PZ2012U600-3R0TF |
| Weight | Contact us |
| Country of Origin | - |
