Please contact us for more photos of HZ1005K601TFB01
| Part Number | HZ1005K601TFB01 |
|---|---|
| Manufacturer | SHENZHEN SUNLORD ELECTRONICS |
| Quantity in stock | 347070 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Chip Bead Shielded Multi-Layer 600 Ohm 25% Ferrite 300mA 0402 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | HZ1005K601TFB01 |
| Datasheet download |  HZ1005K601TFB01.pdf |
| Part Number | HZ1005K601TFB01 |
|---|---|
| Protection Style | Shielded |
| Impedance | 600 Ohm |
| Package/Case | 0402 |
| Supplier Package | 0402 |
| Tolerance | 25 % |
| Type | Chip Bead |
| Package Dimensions | 1 x 0.5 x 0.5 mm |
| Pin Count | 2 |
| Rad Hard | No |
| Operating Temperature | -55 to 125 °C |
| Maximum DC Current | 300 mA |
| Maximum DC Resistance | 0.85 Ohm |
| Core Material | Ferrite |
| Technology | Multilayer |
| Product Depth | 0.5 mm |
| Product Height | 0.5 mm |
| Product Length | 1 mm |
| Replacement Part Number | PART-HZ1005K601TFB01 |
| Weight | Contact us |
| Country of Origin | - |
