Please contact us for more photos of STM32F103ZET6
| Part Number | STM32F103ZET6 |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 738830 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 32-bit STM32F ARM Cortex M3 RISC 512KB Flash 2.5V 3.3V 144-Pin LQFP Tray |
| Category | Microcontrollers MCU IC |
| Family | ARM Based Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | STM32F103ZET6 |
| Datasheet download |  STM32F103ZET6.pdf |
| Part Number | STM32F103ZET6 |
|---|---|
| Data Bus Width | 32 Bit |
| Interface Type | CAN/I2C/SPI/USART/USB |
| Number of Programmable I/Os | 112 |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Watchdog | 2 |
| Device Core | ARM Cortex M3 |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Minimum Operating Supply Voltage | 2 V |
| MSL Level | 3 |
| Maximum Power Dissipation | 666 mW |
| Lead Finish | Matte Tin |
| Maximum Speed | 72 MHz |
| Product Dimensions | 20 x 20 x 1.4 mm |
| On-Chip ADC | 3(21-chx12-bit) |
| Special Features | CAN Controller |
| Program Memory Size | 512 KB |
| Program Memory Type | Flash |
| Instruction Set Architecture | RISC |
| Supplier Package | LQFP |
| Number of Timers | 8 |
| Maximum Operating Supply Voltage | 3.6 V |
| Screening Level | Industrial |
| RAM Size | 64 KB |
| Pin Count | 144 |
| On-Chip DAC | 2(2-chx12-bit) |
| Operating Supply Voltage | 2.5|3.3 V |
| Package | 144LQFP |
| Replacement Part Number | PART-STM32F103ZET6 |
| Weight | Contact us |
| Country of Origin | - |
