Please contact us for more photos of SMA6J12A-TR
| Part Number | SMA6J12A-TR |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 100370 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode TVS Single Uni-Dir 12V 600W 2-Pin SMA T R |
| Category | Circuit Protection |
| Family | TVS |
| ROHS Compliant | Yes |
| MSL Level | SMA6J12A-TR |
| Datasheet download |  SMA6J12A-TR.pdf |
| Part Number | SMA6J12A-TR |
|---|---|
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Mounting | Surface Mount |
| Minimum Breakdown Voltage | 13.3 V |
| Maximum Clamping Voltage | 23.5 V |
| Peak Pulse Power Dissipation | 600 W |
| MSL Level | 1 |
| Direction Type | Uni-Directional |
| Supplier Package | SMA |
| Maximum Reverse Stand-off Voltage | 12 V |
| Maximum Peak Pulse Current | 157 A |
| ESD Protection | Yes |
| Product Dimensions | 4.6 x 2.95 x 2.7 mm |
| Max Processing Temp | 260 |
| Pin Count | 2 |
| Configuration | Single |
| Test Current | 1 mA |
| Maximum Reverse Leakage Current | 0.2 uA |
| Operating Temperature | -55 to 175 °C |
| Package | 2SMA |
| Replacement Part Number | PART-SMA6J12A-TR |
| Weight | Contact us |
| Country of Origin | - |
