Please contact us for more photos of LPS22HB
| Part Number | LPS22HB |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 330690 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MEMS nano pressure sensor: 260-1260 hPa absolute digital output barometer |
| Category | Sensors & Transducers |
| Family | Pressure Sensor |
| ROHS Compliant | Yes |
| MSL Level | LPS22HB |
| Datasheet download |  LPS22HB.pdf |
| Part Number | LPS22HB |
|---|---|
| Operating Pressure Range | 26 to 126 kPa |
| Overload Pressure | 2000 kPa |
| Operating Temperature | -40 to 85 °C |
| Product Dimensions | 2 x 2 x 0.76 |
| Device Pressure Type | Absolute |
| Rad Hard | No |
| Mounting | Surface Mount |
| Pin Count | 10 |
| Operating Supply Voltage | 1.8 V |
| Supplier Package | HLGA |
| Package | 10HLGA |
| Replacement Part Number | PART-LPS22HB |
| Weight | Contact us |
| Country of Origin | - |
