L7809CV-DG STMicroelectronics

L7809CV-DG Images

Please contact us for more photos of L7809CV-DG

Part Number L7809CV-DG
Manufacturer STMicroelectronics
Quantity in stock 885070 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Standard Regulator Pos 9V 1.5A 3-Pin(3+Tab) TO-220 Tube
Category Power Management IC
Family Linear Regulator
ROHS Compliant Yes
MSL Level L7809CV-DG
Datasheet download L7809CV-DG.pdf
Request Quotation for L7809CV-DG

L7809CV-DG Specifications

Part Number L7809CV-DG
Output Type Fixed
Maximum Output Current 1.5 A
Supplier Package TO-220
Load Regulation 180 mV
Input Voltage Range 35 V
Mounting Through Hole
Number of Outputs 1
Product Dimensions 10.4 x 4.6 x 9.15 mm
Pin Count 3
Function Standard
Maximum Quiescent Current 8 mA
Typical Dropout Voltage @ Current 2@1A V
Junction to Case 5 °C/W
Polarity Positive
Output Voltage 9 V
Operating Temperature 0 to 125 °C
Line Regulation 180 mV
Rad Hard No
Junction to Ambient 50 °C/W
Maximum Input Voltage 35 V
Package 3TO-220
Replacement Part Number PART-L7809CV-DG
Weight Contact us
Country of Origin -
