Part Number | TSM-104-02-S-SV |
---|---|
Manufacturer | Samtec |
Quantity in stock | 693680 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn Unshrouded Header HDR 4 POS 2.54mm Solder ST SMD Tube |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | TSM-104-02-S-SV |
Datasheet download | ![]() |
Part Number | TSM-104-02-S-SV |
---|---|
Lead Finish | Matte Tin |
Mounting | Surface Mount |
Operating Temperature | -55 to 125 °C |
Rad Hard | No |
Termination Method | Solder |
Product Dimensions | 10.16 x 2.54 x 11.94 mm |
MSL Level | 1 |
Body Orientation | Straight |
Housing Color | Black |
Gender | HDR |
Pitch | 2.54 mm |
Housing Material | Liquid Crystal Polymer |
Max Processing Temp | 260 |
Contact Plating | Gold Over Nickel |
Contact Material | Phosphor Bronze |
Product Depth | 2.54 mm |
Product Height | 11.94 mm |
Product Length | 10.16 mm |
Replacement Part Number | PART-TSM-104-02-S-SV |
Weight | Contact us |
Country of Origin | - |
