| Part Number | TSM-104-01-S-SV-P-TR |
|---|---|
| Manufacturer | Samtec |
| Quantity in stock | 288170 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Unshrouded Header HDR 4 POS 2.54mm Solder ST SMD T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | TSM-104-01-S-SV-P-TR |
| Datasheet download |  TSM-104-01-S-SV-P-TR.pdf |
| Part Number | TSM-104-01-S-SV-P-TR |
|---|---|
| Rad Hard | No |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Operating Temperature | -55 to 125 °C |
| Termination Method | Solder |
| MSL Level | 1 |
| Body Orientation | Straight |
| Gender | HDR |
| Housing Color | Black |
| Pitch | 2.54 mm |
| Product Dimensions | 10.16 x 2.54 x 9.65 mm |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Max Processing Temp | 260 |
| Contact Plating | Gold Over Nickel |
| Product Depth | 2.54 mm |
| Product Height | 9.65 mm |
| Product Length | 10.16 mm |
| Replacement Part Number | PART-TSM-104-01-S-SV-P-TR |
| Weight | Contact us |
| Country of Origin | - |
