Please contact us for more photos of SEAM-20-11.0-S-06-2-A-K-TR
| Part Number | SEAM-20-11.0-S-06-2-A-K-TR |
|---|---|
| Manufacturer | Samtec |
| Quantity in stock | 838740 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Open Pin Field Array HDR 120 POS 1.27mm Solder ST SMD T R |
| Category | Connectors |
| Family | Connector Terminals |
| ROHS Compliant | Yes |
| MSL Level | SEAM-20-11.0-S-06-2-A-K-TR |
| Datasheet download |  SEAM-20-11.0-S-06-2-A-K-TR.pdf |
| Part Number | SEAM-20-11.0-S-06-2-A-K-TR |
|---|---|
| Lead Finish | Matte Tin |
| Termination Method | Solder |
| Mounting | Surface Mount |
| Rad Hard | No |
| Operating Temperature | -55 to 125 °C |
| Maximum Contact Resistance | 5.5 |
| MSL Level | 1 |
| Housing Color | Black |
| Body Orientation | Straight |
| Maximum Current Rating | 2.3/Contact |
| Product Dimensions | 29.11 x 9.6 x 14.72 mm |
| Housing Material | Liquid Crystal Polymer |
| Max Processing Temp | 260 |
| Maximum Voltage Rating | 240 |
| Type | Open Pin Field Array |
| Contact Plating | Gold Over Nickel |
| Contact Material | Copper Alloy |
| Gender | HDR |
| Pitch | 1.27 mm |
| Product Depth | 9.6 mm |
| Product Height | 14.72 mm |
| Product Length | 29.11 mm |
| Replacement Part Number | PART-SEAM-20-11.0-S-06-2-A-K-TR |
| Weight | Contact us |
| Country of Origin | - |
