EHF-105-01-L-D Samtec

EHF-105-01-L-D Images

Please contact us for more photos of EHF-105-01-L-D

Part Number EHF-105-01-L-D
Manufacturer Samtec
Quantity in stock 268920 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Conn Ejector Header HDR 10 POS 1.27mm Solder ST Thru-Hole Tube
Category Connectors
Family Connector Headers and PCB Receptacles
ROHS Compliant Yes
MSL Level EHF-105-01-L-D
Datasheet download EHF-105-01-L-D.pdf
Request Quotation for EHF-105-01-L-D

EHF-105-01-L-D Specifications

Part Number EHF-105-01-L-D
Lead Finish Matte Tin
Rad Hard No
Operating Temperature -55 to 125 °C
Housing Color Black
Body Orientation Straight
Termination Method Solder
Gender HDR
Product Dimensions 20.83 x 6.67 x 11.3 mm
Housing Material Liquid Crystal Polymer
Number of Rows 2
Mounting Through Hole
Contact Plating Gold Over Nickel
Pitch 1.27 mm
Max Processing Temp 260
Contact Material Phosphor Bronze
Product Depth 6.67 mm
Product Height 11.3 mm
Product Length 20.83 mm
Replacement Part Number PART-EHF-105-01-L-D
Weight Contact us
Country of Origin -
