Please contact us for more photos of UCR10EVHFSR016
| Part Number | UCR10EVHFSR016 |
|---|---|
| Manufacturer | ROHM |
| Quantity in stock | 363260 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 0805 16m Ohm 1% 1 3W 0 to 250ppm \u00b0C Molded SMD Paper T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | UCR10EVHFSR016 |
| Datasheet download |  UCR10EVHFSR016.pdf |
| Part Number | UCR10EVHFSR016 |
|---|---|
| Military Standard | |
| Failure Rate | |
| Resistance Value | 16 MOhm |
| Package Type | SMD |
| Rad Hard | No |
| Pin Count | 2 |
| Case Style | Molded |
| Supplier Package | 0805 |
| Max Processing Temp | 260 |
| Type | Thick Film |
| Power Rating | 0.33 W |
| Termination Style | Wraparound |
| Mounting | Surface Mount |
| Product Dimensions | 2 x 1.25 x 0.55 |
| Case Size | 0805 |
| Temperature Coefficient | 0 to 250 ppm/°C |
| Operating Temperature | -55 to 155 °C |
| Lead Finish | Tin Over Nickel |
| Tolerance | 1 % |
| Product Depth | 1.25 mm |
| Product Height | 0.55 mm |
| Product Length | 2 mm |
| Replacement Part Number | PART-UCR10EVHFSR016 |
| Weight | Contact us |
| Country of Origin | - |
