Please contact us for more photos of TCSM1A226M8R-02
| Part Number | TCSM1A226M8R-02 |
|---|---|
| Manufacturer | ROHM |
| Quantity in stock | 352480 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 22uF 10V M CASE 20% (1.6 X 0.85 X 0.8mm) SMD 1608-10 5 Ohm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | TCSM1A226M8R-02 |
| Datasheet download |  TCSM1A226M8R-02.pdf |
| Part Number | TCSM1A226M8R-02 |
|---|---|
| Military Standard | |
| Failure Rate | |
| Dissipation Factor | 30 % |
| Product Dimensions | 1.6 x 0.85 x 0.8 |
| Max Processing Temp | 260 |
| Pin Count | 2 |
| Tolerance | 20 % |
| Case Style | Molded |
| Rad Hard | No |
| Supplier Package | 0603 |
| Equivalent Series Resistance | 5 Ohm |
| Leakage Current | 11@5Min uA |
| Polarity | Polar |
| Construction | Flat |
| Case Code | M |
| Mounting | Surface Mount |
| Capacitance Value | 22 uF |
| Case Size | 0603 |
| Operating Temperature | -55 to 125 °C |
| Package/Case | 1608-10,M |
| Voltage(DC) | 10 V |
| Product Depth | 0.85 mm |
| Product Height | 0.8 mm |
| Product Length | 1.6 mm |
| Replacement Part Number | PART-TCSM1A226M8R-02 |
| Weight | Contact us |
| Country of Origin | - |
