Please contact us for more photos of MNR12E0APJ103
| Part Number | MNR12E0APJ103 |
|---|---|
| Manufacturer | ROHM |
| Quantity in stock | 808480 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film NET 10K Ohm 5% \u00b1200ppm \u00b0C ISOL Molded 4-Pin Convex 0606 SMD Paper T R |
| Category | Resistor |
| Family | Resistor Networks and Arrays |
| ROHS Compliant | Yes |
| MSL Level | MNR12E0APJ103 |
| Datasheet download |  MNR12E0APJ103.pdf |
| Part Number | MNR12E0APJ103 |
|---|---|
| Technology | Thick Film |
| Package Type | SMD |
| Mounting | Surface Mount |
| Circuit Designator | ISOL |
| Maximum Processing Temperature | 260 °C |
| Pin Count | 4 |
| Case Size per Element | 0603 |
| Terminal Pitch | 0.8 mm |
| Type | Network |
| Number of Terminals | 4 |
| Lead Finish | Tin Over Nickel |
| Supplier Package | 0606 |
| Operating Temperature | -55 to 155 °C |
| Case Size | 0606 |
| Package Dimensions | 1.6 x 1.6 x 0.5 mm |
| Termination Style | Convex |
| Resistance Value | 10 kOhm |
| Number of Resistors | 2 |
| Termination Material | Nickel |
| Rad Hard | No |
| Tolerance | 5 % |
| Case Style | Molded |
| Temperature Coefficient | ±200 ppm/°C |
| Product Depth | 1.6 mm |
| Product Height | 0.5 mm |
| Product Length | 1.6 mm |
| Replacement Part Number | PART-MNR12E0APJ103 |
| Weight | Contact us |
| Country of Origin | - |
