Part Number | LA-101VA |
---|---|
Manufacturer | ROHM |
Quantity in stock | 393460 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Displays Segmented Module 1DIGIT 8LED Red 10-Pin DIP Film Pack |
Category | Optoelectronics |
Family | LED Displays |
ROHS Compliant | Yes |
MSL Level | LA-101VA |
Datasheet download | ![]() |
Part Number | LA-101VA |
---|---|
Total Thickness | 10.5 mm |
Viewing Area Length | 14.1 mm |
Peak Wavelength | 650 nm |
Maximum Reverse Current | 100 uA |
Supplier Package | DIP |
Pin Count | 10 |
Maximum Forward Voltage | 2.8 V |
Operating Temperature | -25 to 75 °C |
Mounting | Through Hole |
Type | Module |
Maximum Reverse Voltage | 3 V |
Maximum Forward Current | 15 mA |
Lead Finish | Tin-Copper/Tin |
Maximum Processing Temperature | 260 °C |
Rad Hard | No |
Pattern Graphics | Segmented |
Color | Red |
Intensity | 10000 ucd |
No of Digits | 1 |
Package Dimensions | 24 x 34 x 10.5 mm |
Viewing Area Height | 25.4 mm |
No of LED'S | 8 |
Package | 10DIP |
Replacement Part Number | PART-LA-101VA |
Weight | Contact us |
Country of Origin | - |
