Please contact us for more photos of HSMS-285B-TR1G
| Part Number | HSMS-285B-TR1G |
|---|---|
| Manufacturer | Broadcom |
| Quantity in stock | 820380 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode RF Detector Schottky 2V 3-Pin SOT-323 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | HSMS-285B-TR1G |
| Datasheet download |  HSMS-285B-TR1G.pdf |
| Part Number | HSMS-285B-TR1G |
|---|---|
| Lead Finish | Matte Tin |
| MSL Level | 1 |
| Mounting | Surface Mount |
| Pin Count | 3 |
| Typical Tangential Sensitivity | -57@915MHz dBm |
| Configuration | Single |
| Rad Hard | No |
| Maximum Forward Voltage | 0.25@1mA V |
| Type | Schottky Diode |
| Supplier Package | SOT-323 |
| Typical Voltage Sensitivity | 40@915MHz mV/uW |
| Frequency Range | UHF |
| Typical Video Resistance | 8 kOhm |
| Product Dimensions | 2.25 x 1.4 x 1 mm |
| Maximum Reverse Voltage | 2 V |
| Max Processing Temp | 260 |
| Package | 3SOT-323 |
| Replacement Part Number | PART-HSMS-285B-TR1G |
| Weight | Contact us |
| Country of Origin | - |
