Part Number | R5F109BCJNA#U0 |
---|---|
Manufacturer | Renesas Electronics |
Quantity in stock | 215900 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | MCU 16-Bit RL78 F12 RL78 CISC 32KB Flash 3.3V 5V 32-Pin HWQFN EP Tray |
Category | Microcontrollers MCU IC |
Family | 16 Bit Microcontrollers MCU |
ROHS Compliant | Yes |
MSL Level | R5F109BCJNA#U0 |
Datasheet download | ![]() |
Part Number | R5F109BCJNA#U0 |
---|---|
Instruction Set Architecture | CISC |
Product Dimensions | 5 x 5 x 0.8(Max) |
Rad Hard | No |
Pin Count | 32 |
Maximum Expanded Memory Size | 1 MB |
Number of Programmable I/Os | 28 |
Screening Level | Automotive |
Operating Temperature | -40 to 85 °C |
Maximum Operating Supply Voltage | 5.5 V |
Interface Type | CSI/I2C/LIN/UART |
Mounting | Surface Mount |
Operating Supply Voltage | 3.3|5 V |
Data Memory Size | 4 KB |
Program Memory Size | 32 KB |
On-Chip ADC | 8-chx10-bit |
Number of Timers | 10 |
Maximum Speed | 32 MHz |
Minimum Operating Supply Voltage | 1.8 V |
RAM Size | 2 KB |
Supplier Package | HWQFN EP |
Package | 32HWQFN EP |
Replacement Part Number | PART-R5F109BCJNA#U0 |
Weight | Contact us |
Country of Origin | - |
