VS-STPS1045BTRPbF Vishay

VS-STPS1045BTRPbF Images

Please contact us for more photos of VS-STPS1045BTRPbF

Part Number VS-STPS1045BTRPbF
Manufacturer Vishay
Quantity in stock 804640 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Schottky 45V 10A 3-Pin(2+Tab) DPAK T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level VS-STPS1045BTRPbF
Datasheet download VS-STPS1045BTRPbF.pdf
Request Quotation for VS-STPS1045BTRPbF

VS-STPS1045BTRPbF Specifications

Part Number VS-STPS1045BTRPbF
Configuration Single Dual Anode
Operating Temperature -40 to 175 °C
Supplier Package DPAK
Rad Hard No
Peak Average Forward Current 10 A
Peak Reverse Current 200 uA
Max Processing Temp 260
Type Schottky Diode
Peak Forward Voltage 0.84@20A V
Mounting Surface Mount
Peak Non-Repetitive Surge Current 390 A
Peak Reverse Repetitive Voltage 45 V
Lead Finish Tin
Product Dimensions 6.73 x 6.22 x 2.39 mm
Pin Count 3
MSL Level 1
Package 3DPAK
Replacement Part Number PART-VS-STPS1045BTRPbF
Weight Contact us
Country of Origin -
