STTH8R04G-TR STMicroelectronics

STTH8R04G-TR Images

Please contact us for more photos of STTH8R04G-TR

Part Number STTH8R04G-TR
Manufacturer STMicroelectronics
Quantity in stock 349990 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Switching 400V 8A 3-Pin(2+Tab) D2PAK T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level STTH8R04G-TR
Datasheet download STTH8R04G-TR.pdf
Request Quotation for STTH8R04G-TR

STTH8R04G-TR Specifications

Part Number STTH8R04G-TR
Max Processing Temp 245
Peak Average Forward Current 8 A
Peak Non-Repetitive Surge Current 120 A
Configuration Single
Rad Hard No
Operating Temperature -40 to 175 °C
Peak Reverse Current 10 uA
Supplier Package D2PAK
Peak Reverse Recovery Time 50 ns
Peak Forward Voltage 1.5 V
Peak Reverse Repetitive Voltage 400 V
Product Dimensions 10.4 x 9.35 x 4.6 mm
Lead Finish Matte Tin
Mounting Surface Mount
Pin Count 3
Type Switching Diode
MSL Level 1
Package 3D2PAK
Replacement Part Number PART-STTH8R04G-TR
Weight Contact us
Country of Origin -
