Please contact us for more photos of STTH3006DPI
| Part Number | STTH3006DPI |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 889420 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 600V 30A 2-Pin(2+Tab) DOP3I |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | STTH3006DPI |
| Datasheet download |  STTH3006DPI.pdf |
| Part Number | STTH3006DPI |
|---|---|
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Peak Reverse Repetitive Voltage | 600 V |
| Peak Non-Repetitive Surge Current | 180 A |
| Type | Switching Diode |
| Operating Temperature | -65 to 150 °C |
| Peak Forward Voltage | 3.6 V |
| Peak Average Forward Current | 30 A |
| Peak Reverse Current | 40 uA |
| Configuration | Single |
| Pin Count | 2 |
| Product Dimensions | 15.5 x 4.6 x 12.85 mm |
| Supplier Package | DOP3I |
| Mounting | Through Hole |
| Peak Reverse Recovery Time | 45 ns |
| Package | 2DOP3I |
| Replacement Part Number | PART-STTH3006DPI |
| Weight | Contact us |
| Country of Origin | - |
