SDM40E20LA-7 Diodes Incorporated

SDM40E20LA-7 Images

Please contact us for more photos of SDM40E20LA-7

Part Number SDM40E20LA-7
Manufacturer Diodes Incorporated
Quantity in stock 848520 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Schottky 20V 0.4A 3-Pin SOT-23 T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level SDM40E20LA-7
Datasheet download SDM40E20LA-7.pdf
Request Quotation for SDM40E20LA-7

SDM40E20LA-7 Specifications

Part Number SDM40E20LA-7
Rad Hard No
Peak Average Forward Current 0.4 A
Product Dimensions 2.9 x 1.3 x 1 mm
Type Schottky Diode
Peak Reverse Current 250 uA
Peak Reverse Repetitive Voltage 20 V
Peak Non-Repetitive Surge Current 2 A
Max Processing Temp 260
Configuration Dual Common Anode
Lead Finish Matte Tin
Peak Forward Voltage [email protected] V
Mounting Surface Mount
Supplier Package SOT-23
Pin Count 3
MSL Level 1
Operating Temperature -65 to 125 °C
Package 3SOT-23
Replacement Part Number PART-SDM40E20LA-7
Weight Contact us
Country of Origin -
