Please contact us for more photos of S07J-GS08
| Part Number | S07J-GS08 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 536760 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Small Signal Switching 600V 1.5A 2-Pin DO-219AB T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | S07J-GS08 |
| Datasheet download |  S07J-GS08.pdf |
| Part Number | S07J-GS08 |
|---|---|
| Lead Finish | Matte Tin |
| Rad Hard | No |
| MSL Level | 1 |
| Mounting | Surface Mount |
| Type | Small Signal Switching Diode |
| Operating Temperature | -55 to 150 °C |
| Peak Reverse Repetitive Voltage | 600 V |
| Peak Reverse Recovery Time | 1800 ns |
| Peak Average Forward Current | 1.5 A |
| Peak Forward Voltage | 1.1@1A V |
| Supplier Package | DO-219AB |
| Product Dimensions | 2.9 x 1.9 x 1.08 mm |
| Pin Count | 2 |
| Max Processing Temp | 260 |
| Peak Reverse Current | 10 uA |
| Configuration | Single |
| Peak Non-Repetitive Surge Current | 25 A |
| Package | 2DO-219AB |
| Replacement Part Number | PART-S07J-GS08 |
| Weight | Contact us |
| Country of Origin | - |
