RB521CS30L,315 Nexperia

RB521CS30L,315 Images

Please contact us for more photos of RB521CS30L,315

Part Number RB521CS30L,315
Manufacturer Nexperia
Quantity in stock 734690 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Schottky 30V 0.1A 2-Pin SOD-882 T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level RB521CS30L,315
Datasheet download RB521CS30L,315.pdf
Request Quotation for RB521CS30L,315

RB521CS30L,315 Specifications

Part Number RB521CS30L,315
Peak Average Forward Current 0.1 A
Operating Temperature -65 to 150 °C
Peak Forward Voltage [email protected] V
Peak Reverse Repetitive Voltage 30 V
Supplier Package SOD-882
Max Processing Temp 260
Peak Non-Repetitive Surge Current 3 A
Peak Reverse Current 10@10V uA
Pin Count 2
Configuration Single
Type Schottky Diode
Rad Hard No
MSL Level 1
Product Dimensions 1.02 x 0.62 x 0.47 mm
Lead Finish Tin
Mounting Surface Mount
Package 2SOD-882
Replacement Part Number PART-RB521CS30L,315
Weight Contact us
Country of Origin -
