Please contact us for more photos of RB080L-30TE25
| Part Number | RB080L-30TE25 |
|---|---|
| Manufacturer | ROHM |
| Quantity in stock | 215240 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 30V 5A 2-Pin PMDS T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | RB080L-30TE25 |
| Datasheet download |  RB080L-30TE25.pdf |
| Part Number | RB080L-30TE25 |
|---|---|
| Product Dimensions | 4.5 x 2.6 x 1.9 mm |
| Peak Reverse Current | 150 uA |
| Mounting | Surface Mount |
| Max Processing Temp | 260|265 |
| Supplier Package | PMDS |
| Peak Average Forward Current | 5 A |
| Peak Forward Voltage | 0.51 V |
| Peak Non-Repetitive Surge Current | 70 A |
| Peak Reverse Repetitive Voltage | 30 V |
| Pin Count | 2 |
| Rad Hard | No |
| Lead Finish | Tin/Silver/Copper |
| Type | Schottky Diode |
| Configuration | Single |
| Operating Temperature | -55 to 150 °C |
| Package | 2PMDS |
| Replacement Part Number | PART-RB080L-30TE25 |
| Weight | Contact us |
| Country of Origin | - |
