Please contact us for more photos of NRVTS1045EMFST3G
| Part Number | NRVTS1045EMFST3G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 156160 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 45V 10A 8-Pin SO-FL T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | NRVTS1045EMFST3G |
| Datasheet download |  NRVTS1045EMFST3G.pdf |
| Part Number | NRVTS1045EMFST3G |
|---|---|
| Peak Reverse Repetitive Voltage | 45 V |
| Pin Count | 8 |
| Screening Level | Automotive |
| Peak Average Forward Current | 10 A |
| Operating Temperature | -55 to 150 °C |
| Peak Non-Repetitive Surge Current | 210 A |
| Peak Reverse Current | 50 uA |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Mounting | Surface Mount |
| Configuration | Single Triple Anode Dual Cathode |
| Max Processing Temp | 260 |
| Supplier Package | SO-FL |
| MSL Level | 1 |
| Peak Forward Voltage | 0.6@10A V |
| Product Dimensions | 4.9 x 5.9 x 1.05(Max) |
| Type | Schottky Diode |
| Package | 8SO-FL |
| Replacement Part Number | PART-NRVTS1045EMFST3G |
| Weight | Contact us |
| Country of Origin | - |
