MMBD1504A Fairchild Semiconductor

Please contact us for more photos of MMBD1504A

Part Number	MMBD1504A
Manufacturer	Fairchild Semiconductor
Quantity in stock	587830 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Diode Small Signal Switching 200V 0.2A 3-Pin SOT-23 T R
Category	Discrete Semiconductor
Family	Diode
ROHS Compliant	Yes
MSL Level	MMBD1504A
Datasheet download	MMBD1504A.pdf

Request Quotation for MMBD1504A

MMBD1504A Specifications

Part Number	MMBD1504A
Mounting	Surface Mount
Rad Hard	No
Product Dimensions	2.92 x 1.3 x 0.93 mm
Configuration	Dual Common Cathode
Peak Reverse Repetitive Voltage	200 V
Peak Average Forward Current	0.2 A
Lead Finish	Matte Tin
Max Processing Temp	260
Peak Forward Voltage	[email protected] V
MSL Level	1
Peak Non-Repetitive Surge Current	2 A
Peak Reverse Current	0.01@180V uA
Type	Small Signal Switching Diode
Operating Temperature	-55 to 150 °C
Supplier Package	SOT-23
Pin Count	3
Package	3SOT-23
Replacement Part Number	PART-MMBD1504A
Weight	Contact us
Country of Origin	-
