MBRS4201T3G ON Semiconductor

MBRS4201T3G Images

Please contact us for more photos of MBRS4201T3G

Part Number MBRS4201T3G
Manufacturer ON Semiconductor
Quantity in stock 408060 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Schottky 200V 4A 2-Pin SMC T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level MBRS4201T3G
Datasheet download MBRS4201T3G.pdf
Request Quotation for MBRS4201T3G

MBRS4201T3G Specifications

Part Number MBRS4201T3G
Product Dimensions 6.86 x 5.84 x 2.13 mm
Peak Average Forward Current 4 A
Pin Count 2
Configuration Single
Rad Hard No
Operating Temperature -55 to 150 °C
Type Schottky Diode
Peak Forward Voltage 0.8 V
Max Processing Temp 260
Peak Reverse Current 0.35 uA
Peak Reverse Repetitive Voltage 200 V
Lead Finish Matte Tin
Mounting Surface Mount
Peak Non-Repetitive Surge Current 100 A
Supplier Package SMC
MSL Level 1
Peak Reverse Recovery Time 35 ns
Package 2SMC
Replacement Part Number PART-MBRS4201T3G
Weight Contact us
Country of Origin -
