Please contact us for more photos of MBR20L45CTG
| Part Number | MBR20L45CTG |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 278630 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 45V 10A 3-Pin(3+Tab) TO-220AB Rail |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | MBR20L45CTG |
| Datasheet download |  MBR20L45CTG.pdf |
| Part Number | MBR20L45CTG |
|---|---|
| Peak Forward Voltage | 0.63@20A V |
| Supplier Package | TO-220AB |
| Operating Temperature | -55 to 150 °C |
| Rad Hard | No |
| Type | Schottky Diode |
| Max Processing Temp | 260 |
| Peak Average Forward Current | 10 A |
| Peak Non-Repetitive Surge Current | 180 A |
| Lead Finish | Matte Tin |
| Peak Reverse Repetitive Voltage | 45 V |
| Product Dimensions | 10.28 x 4.82 x 9.28 mm |
| Mounting | Through Hole |
| Peak Reverse Current | 500 uA |
| Pin Count | 3 |
| Configuration | Dual Common Cathode |
| Package | 3TO-220AB |
| Replacement Part Number | PART-MBR20L45CTG |
| Weight | Contact us |
| Country of Origin | - |
