Please contact us for more photos of MBR1035G
| Part Number | MBR1035G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 555480 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 35V 10A 2-Pin(2+Tab) TO-220AC Rail |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | MBR1035G |
| Datasheet download |  MBR1035G.pdf |
| Part Number | MBR1035G |
|---|---|
| Lead Finish | Matte Tin |
| Peak Reverse Repetitive Voltage | 35 V |
| Peak Reverse Current | 100 uA |
| Mounting | Through Hole |
| Peak Non-Repetitive Surge Current | 150 A |
| Product Dimensions | 10.29 x 4.82 x 9.27 mm |
| Supplier Package | TO-220AC |
| Peak Forward Voltage | 0.84@20A V |
| Pin Count | 2 |
| Type | Schottky Diode |
| Peak Average Forward Current | 10 A |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Configuration | Single |
| Operating Temperature | -65 to 175 °C |
| Package | 2TO-220AC |
| Replacement Part Number | PART-MBR1035G |
| Weight | Contact us |
| Country of Origin | - |
