Part Number | IMN10T108 |
---|---|
Manufacturer | ROHM |
Quantity in stock | 483990 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Diode Switching 80V 0.3A 6-Pin SMD T R |
Category | Discrete Semiconductor |
Family | Diode |
ROHS Compliant | Yes |
MSL Level | IMN10T108 |
Datasheet download | ![]() |
Part Number | IMN10T108 |
---|---|
Configuration | Triple Parallel |
Supplier Package | SMD |
Peak Reverse Repetitive Voltage | 80 V |
Rad Hard | No |
Lead Finish | Tin/Silver/Copper |
Peak Average Forward Current | 0.3 A |
Operating Temperature | -55 to 150 °C |
Peak Reverse Recovery Time | 4 ns |
Peak Non-Repetitive Surge Current | 4 A |
Peak Forward Voltage | [email protected] V |
Mounting | Surface Mount |
Peak Reverse Current | 0.1@70V uA |
Product Dimensions | 2.9 x 1.6 x 1.1 mm |
Max Processing Temp | 260|265 |
Pin Count | 6 |
Type | Switching Diode |
Package | 6SMD |
Replacement Part Number | PART-IMN10T108 |
Weight | Contact us |
Country of Origin | - |
