FCHS30A08 Nihon Inter

FCHS30A08 Images

Please contact us for more photos of FCHS30A08

Part Number FCHS30A08
Manufacturer Nihon Inter
Quantity in stock 232650 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Schottky Barrier 80V 30A 3-Pin TO-220
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level FCHS30A08
Datasheet download FCHS30A08.pdf
Request Quotation for FCHS30A08

FCHS30A08 Specifications

Part Number FCHS30A08
Peak Average Forward Current 30 A
Rad Hard No
Peak Reverse Repetitive Voltage 80 V
Type Schottky Barrier Diode
Peak Non-Repetitive Surge Current 200 A
Peak Reverse Current 200 uA
Peak Forward Voltage 0.72@15A V
Package Dimensions 10.1 x 4.5 x 15.1 mm
Supplier Package TO-220
Operating Temperature -40 to 150 °C
Lead Finish Tin
Configuration Dual Common Cathode
Pin Count 3
Mounting Through Hole
Package 3TO-220
Replacement Part Number PART-FCHS30A08
Weight Contact us
Country of Origin -
