BAW56LT3G ON Semiconductor

BAW56LT3G Images

Please contact us for more photos of BAW56LT3G

Part Number BAW56LT3G
Manufacturer ON Semiconductor
Quantity in stock 347580 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Small Signal Switching 70V 0.2A 3-Pin SOT-23 T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level BAW56LT3G
Datasheet download BAW56LT3G.pdf
Request Quotation for BAW56LT3G

BAW56LT3G Specifications

Part Number BAW56LT3G
Peak Forward Voltage [email protected] V
Lead Finish Matte Tin
Mounting Surface Mount
Supplier Package SOT-23
Peak Reverse Repetitive Voltage 70 V
Pin Count 3
MSL Level 1
Peak Non-Repetitive Surge Current 4 A
Max Processing Temp 260
Rad Hard No
Operating Temperature -55 to 150 °C
Peak Average Forward Current 0.2 A
Peak Reverse Current 2.5 uA
Peak Reverse Recovery Time 6 ns
Product Dimensions 2.9 x 1.3 x 0.94 mm
Configuration Dual Common Anode
Type Small Signal Switching Diode
Package 3SOT-23
Replacement Part Number PART-BAW56LT3G
Weight Contact us
Country of Origin -
