Please contact us for more photos of BAV23 DG B2,215
| Part Number | BAV23 DG B2,215 |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 790110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 250V 0.225A 4-Pin SOT-143B T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAV23 DG B2,215 |
| Datasheet download |  BAV23 DG B2,215.pdf |
| Part Number | BAV23 DG B2,215 |
|---|---|
| Package Dimensions | 2.9 x 1.3 x 1 mm |
| Configuration | Dual Parallel |
| Supplier Package | SOT-143B |
| Screening Level | Automotive |
| Peak Average Forward Current | 0.225 A |
| Pin Count | 4 |
| Peak Reverse Repetitive Voltage | 250 V |
| Peak Reverse Recovery Time | 50 ns |
| Peak Reverse Current | 0.1@200V uA |
| Rad Hard | No |
| Mounting | Surface Mount |
| Type | Switching Diode |
| Lead Finish | Tin |
| Peak Non-Repetitive Surge Current | 9 A |
| Moisture Sensitivity Level | 1 |
| Operating Temperature | -65 to 150 °C |
| Peak Forward Voltage | 1.25@200mA V |
| Maximum Processing Temperature | 260 °C |
| Package | 4SOT-143B |
| Replacement Part Number | PART-BAV23 DG B2,215 |
| Weight | Contact us |
| Country of Origin | - |
