BAT760-7 Diodes Incorporated

Please contact us for more photos of BAT760-7

Part Number	BAT760-7
Manufacturer	Diodes Incorporated
Quantity in stock	338150 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Diode Schottky 30V 1A 2-Pin SOD-323 T R
Category	Discrete Semiconductor
Family	Diode
ROHS Compliant	Yes
MSL Level	BAT760-7
Datasheet download	BAT760-7.pdf

Request Quotation for BAT760-7

BAT760-7 Specifications

Part Number	BAT760-7
Peak Reverse Current	50@15V uA
Pin Count	2
Peak Non-Repetitive Surge Current	5.5 A
Peak Forward Voltage	0.55 V
Rad Hard	No
Configuration	Single
Type	Schottky Diode
Max Processing Temp	260
Peak Reverse Repetitive Voltage	30 V
Operating Temperature	-65 to 150 °C
Product Dimensions	1.8 x 1.4 x 1 mm
Lead Finish	Matte Tin
Mounting	Surface Mount
Peak Average Forward Current	1 A
MSL Level	1
Supplier Package	SOD-323
Package	2SOD-323
Replacement Part Number	PART-BAT760-7
Weight	Contact us
Country of Origin	-
