Please contact us for more photos of 1SS404TPH3F
| Part Number | 1SS404TPH3F |
|---|---|
| Manufacturer | Toshiba |
| Quantity in stock | 641250 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky Barrier Diode 25V 0.3A 2-Pin USC Embossed T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | 1SS404TPH3F |
| Datasheet download |  1SS404TPH3F.pdf |
| Part Number | 1SS404TPH3F |
|---|---|
| Pin Count | 2 |
| Product Dimensions | 1.7 x 1.25 x 0.9 |
| Peak Forward Voltage | 0.45 V |
| Supplier Package | USC |
| Operating Temperature | -40 to 100 °C |
| Peak Reverse Repetitive Voltage | 25 V |
| Type | Schottky Barrier Diode |
| Peak Reverse Current | 50@20V uA |
| Peak Non-Repetitive Surge Current | 0.7 A |
| Mounting | Surface Mount |
| Rad Hard | No |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Lead Finish | Tin|Silver |
| Peak Average Forward Current | 0.3 A |
| Configuration | Single |
| Package | 2USC |
| Replacement Part Number | PART-1SS404TPH3F |
| Weight | Contact us |
| Country of Origin | - |
