12CWQ10FNTRPBF Vishay

12CWQ10FNTRPBF Images

Please contact us for more photos of 12CWQ10FNTRPBF

Part Number 12CWQ10FNTRPBF
Manufacturer Vishay
Quantity in stock 649170 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Schottky 100V 12A 3-Pin(2+Tab) DPAK T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level 12CWQ10FNTRPBF
Datasheet download 12CWQ10FNTRPBF.pdf
Request Quotation for 12CWQ10FNTRPBF

12CWQ10FNTRPBF Specifications

Part Number 12CWQ10FNTRPBF
Operating Temperature -55 to 150 °C
Type Schottky Diode
Max Processing Temp 260
Supplier Package DPAK
Peak Reverse Current 1000 uA
Peak Average Forward Current 12 A
Mounting Surface Mount
Peak Non-Repetitive Surge Current 330 A
Product Dimensions 6.73 x 6.22 x 2.39 mm
Peak Reverse Repetitive Voltage 100 V
Lead Finish Tin
MSL Level 1
Pin Count 3
Configuration Dual Common Cathode
Peak Forward Voltage 0.95 V
Package 3DPAK
Replacement Part Number PART-12CWQ10FNTRPBF
Weight Contact us
Country of Origin -
