PA2050.193NL Pulse

PA2050.193NL Images

Please contact us for more photos of PA2050.193NL

Part Number PA2050.193NL
Manufacturer Pulse
Quantity in stock 518970 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind Power Wirewound 19.4uH 10% 8.5A
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level PA2050.193NL
Datasheet download PA2050.193NL.pdf
Request Quotation for PA2050.193NL

PA2050.193NL Specifications

Part Number PA2050.193NL
Minimum Quality Factor
Tolerance 10 %
Impedance
Core Material
Max Processing Temp 245
Package/Case 22.23 X 19.05 X 12.2
Product Dimensions 22.23 x 19.05 x 12.2 mm
Maximum DC Resistance 12.6 mOhm
Maximum DC Current 8.5 A
Inductance 19.4 uH
Operating Temperature -55 to 130 °C
Maximum Self Resonant Frequency
Rad Hard No
Type Power
Technology Wirewound
Product Depth 19.05 mm
Product Height 12.2 mm
Product Length 22.23 mm
Replacement Part Number PART-PA2050.193NL
Weight Contact us
Country of Origin -
